Brand Name : TISCO
Model Number : 430 / 1.4016 / SUS430
Certification : ISO
Place of Origin : China
MOQ : 500 kgs
Price : 1220 - 1450 USD/Ton
Payment Terms : L/C, T/T, Western Union
Supply Ability : 20Ton per week
Delivery Time : 5 - 12 days based on the quantity
Packaging Details : standard packing for export
Products : stainless steel coil & Band
Thickness : 0.1-3.0mm
Width : within 1000mm 1219mm
MOQ : 200 kgs
Grade : EN 1.4016 Stainless Steel
Surface : BA 2B NO.4 HL 8K NO.1 2D
Standard : ASTM EN GB JIS
Packing : wooden frame and water proof paper
EN 10088 Grade 1.4016 Stainless Steel Strip & Coils Thickness 0.1 - 3.0mm SS Strips
Product Name | 430 Stainless Steel Strips |
Material | Stainless Steel |
Standard | ASTM JIS GB EN |
Other Grade | 201 202 301 304 304L 309S 310S 316L 317L 410 420 430 436L 441 2205 2507 904L C276 |
Thickness | 0.05mm-3.0mm |
Width | 30mm-600mm |
Finish | No.1, No.2, Bright Annealed, TR, Polished, etc. |
Edge | Mill edge, Slit edge, Square edge, Round edge, etc. |
Coating | PE coating, Paper coating |
Coil ID | 508mm/610mm |
Payment Terms | T/T, L/C |
Delivery Time | As per quantity required |
Type 430 is a ferritic stainless steel with corrosion resistance approaching that of 304/304L stainless steel. This grade does not work harden rapidly and can be formed using both mild stretch forming, bending, or drawing operations. This grade is used in a variety of interior and exterior cosmetic applications where corrosion resistance is more important than strength. Type 430 has poor weldability compared to most stainless steels due to the higher carbon content and lack of stabilizing elements for this grade, which requires post weld heat treatment to restore the corrosion resistance and ductility. Stabilized grades such as Type 439 and 441
Chemical Composition of EN 1.4016 Stainless Steel
Chemical Composition (wt%) limits as specified in ASTM A240 and ASME SA240*
Grade | C | Cr | Ni | Mn | Si | P | S | Fe |
1.4016 | 0.12 | 16.0-18.0 | 0.75 | 1.00 | 1.00 | 0.040 | 0.030 | Bal |
* Maximum, unless range is indicated
Mechanical Properties of EN 1.4016 Stainless Steel Strip
Mechanical property requirements for annealed product as specified in ASTM A240 and ASME SA240
Property | 430 |
Yield Strength, min. (ksi) | 30 |
Tensile Strength, min. (ksi) | 65 |
Elongation, min. (%) | 22 |
Hardness, max. (Rb) | 89 |
Grade | AISI | EN | UNS | BS | AFNOR | IS | SIS | JIS | UNI |
SS 430 | 430 | 1.4016 | S43000 | 430 S 17 | Z 8 C 17 | X10 Cr 17 | 142320 | SUS 430 | X12Cr17C |
